Regulator Rectifier Voltage Regulator Lithium Yamaha YFZ450 YFZ450R 700 Raptor 450 660 Rhino 660 Grizzly OEM 5BN-81960-00-00

Voltage Regulator compatible with Lithium-Ion Batteries

2024 Yamaha YFZ 450 R SE
2024 Yamaha YFZ 450 R
2023 Yamaha YFZ 450 R SE
2023 Yamaha YFZ 450 R
2023 Yamaha YFM 700 R Raptor
2022 Yamaha YFZ 450 R SE
2022 Yamaha YFZ 450 R
2022 Yamaha YFM 700 R Raptor
2021 Yamaha YFZ 450 R SE
2021 Yamaha YFZ 450 R
2021 Yamaha YFM 700 R Raptor

2020 Yamaha YFZ 450 R
2020 Yamaha YFM 700 R Raptor
2019 Yamaha YFZ 450 R
2019 Yamaha YFM 700 R Raptor
2018 Yamaha YFZ 450 R
2018 Yamaha YFM 700 R Raptor
2017 Yamaha YFZ 450 R
2017 Yamaha YFM 700 R Raptor
2016 Yamaha YFZ 450 R
2016 Yamaha YFM 700 R Raptor
2015 Yamaha YFZ 450 R
2015 Yamaha YFM 700 R Raptor
2014 Yamaha YFZ 450 R
2014 Yamaha YFM 700 R Raptor
2013 Yamaha YFZ 450 R
2013 Yamaha YFM 700 R Raptor
2012 Yamaha YFZ 450 R
2012 Yamaha YFM 700 R Raptor
2011 Yamaha YFZ 450 R
2011 Yamaha YFZ 450
2011 Yamaha YFM 700 R Raptor
2010 Yamaha YFZ 450 R
2010 Yamaha YFZ 450
2010 Yamaha YFM 700 R Raptor
2009 Yamaha YXR 450 Rhino
2009 Yamaha YFZ 450 R
2009 Yamaha YFM 700 R Raptor
2008 Yamaha YXR 450 Rhino
2008 Yamaha YFM 700 R Raptor
2008 Yamaha YFM 660 Grizzly
2007 Yamaha YXR 660 Rhino
2007 Yamaha YXR 450 Rhino
2007 Yamaha YFM 700 R Raptor
2007 Yamaha YFM 660 Grizzly
2006 Yamaha YXR 660 Rhino
2006 Yamaha YXR 450 Rhino
2006 Yamaha YFM 700 R Raptor
2006 Yamaha YFM 660 Grizzly
2005 Yamaha YXR 660 Rhino
2005 Yamaha YFM 660 Grizzly
2004 Yamaha YXR 660 Rhino
2004 Yamaha YFM 660 Grizzly
2003 Yamaha YFM 660 Grizzly
2002 Yamaha YFM 660 Grizzly

Dimensions:
Width: 89 mm
Length: 91 mm
Height: 27 mm
Fixation holes center to center: 66 mm

Other specifications:
Number of plugs: 1
Number of pins: 6
Number of wires: 5
Minimum Charging Voltage: 14.5 V +/- 0.5 V
Maximum Charging Current: 50 A / 500 W
Open Circuit Voltage: < 15 V
Operation Temperature: -20°C to 85°C

OEM
5BN-81960-00-00
